UV Ultra i3200 1702
Roll to Roll UV 1.6m Epson i3200 1702UV

Wit-Color Latest Multicolor Digital R2R UV Printer Ultra i3200 1702

  • Print Width: 1.6m
  • Print Head: Epson i3200
  • Print Head Quantity: 1/2 pcs
  • Inks: UV ink
  • RIP Software: PhotoPrint or Print Factory


Wit-Color NEW Design UV Printer Ultra i3200 1702

Use High Resolution for All Advertising Images
1. Epson i3200 Print Head
2. Maximum Print Width is 1.6m
3. High Quality! Higher Resolution Better Performance!


i3200 Printhead

Equipped with the latest Epson i3200 greyscale printhead, our printing system offers a level of precision and speed that is unmatched in the market. The use of this advanced printhead enables significantly faster printing speeds, while also delivering smoother, higher-quality inkjet output. This means you can now achieve superior print results in a much shorter time, making it the ideal solution for businesses and professionals who require efficient, high-quality printing.


Intelligent Design

The integrated intelligent control system further enhances the performance of our printing technology. This system is designed to optimize the printing process, ensuring uninterrupted operation and consistent output quality. With smart control features, users can experience increased efficiency, reduced downtime, and increased overall productivity.


High Configuration

In addition to its exceptional performance, our High Configuration Integrated Smart Control System is designed with user convenience in mind. The intuitive interface and user-friendly controls make operation easy, allowing users to maximize the full potential of the system without the need for extensive training or technical expertise.


Print Your Dream

Whether you are in the printing industry, graphic design industry, or any other field that requires high-quality printing, our High Configuration Integrated Smart Control System is the ultimate solution for all your printing needs. Experience the power of advanced technology and take your printing capabilities to new heights with our innovative system.

Choose our High Configuration Integrated Smart Control System and take your printing experience to the next level. Join the ranks of satisfied users who have embraced the future of printing technology.

Model UV Ultra i3200 1702/4
Printing Technology UV Printing
Print head EPSON i3200
Accept Media Available Type Backlit flexible, Soft film, Wall cloth, Wallpaper, PP, Vinyl etc.
Width ≦1620mm
Ink Type UV Ink: CMYK LCLM WV
Ink Supply Negative Pressure Ink Supply
Ink Cartridges Capacity Color Syphon+White ink automatic mixing
Color CMYK+LC, LM+W+Varnish
Image Format Tiff, JPEG, EPS, PDF
RIP Software Maintop(standard) Photo Printing/Print Factory(optional)
Print Resolution Maximum
Speed Mode 2S 4H
3 Passes 33㎡/hour 62㎡/hour
4 Passes 21㎡/hour 48㎡/hour
6Pass 11㎡/hour 33㎡/hour
Ink Drying Method UV drying
Control System Win10
Power 6100W
Interface USB3.0 / Gigabit Ethernet
Power Supply AC 220V±10%, 50/60 HZ
POWER SUPPLY 3KVA
Packing Size Inch L: 125.99 x W: 44.10 x H: 43.31 1 Inch=25.4mm
Meters L: 3.2mx W:1.12mx H: 1.1m
Printer Size Inch L: 114.18 x W: 39.38 x H: 66.93 1 Inch=25.4 mm
Meters L:2.9m x W:1m x H:1.7m
Weight General 1078 lbs. 490 kg 1kg=2.2 lb.
Northwest 880 lbs. 400 kg 1kg=2.2 lb.
Environment Power On Temperature 59℉ to 90℉[15℃ to 32℃] Humidity: 35% to 80% (No Condensation)
Power Off Temperature 41℉ to 104℉[5℃ to 40℃] Humidity: 35% to 80% (No Condensation)
Safety Certificate CE Certified


✱About 10% speed may vary depending on different feather printing modes and different PC configurations. All data is subject to change without prior notice.
