UVIP 6090
Flatbed UV Printing Machine 6090
Wit-Color Multicolor Digital UV Printer UVIP Epson 6090
- Print Width: 0.6m*0.9m
- Print Head: Epson i3200
- Print Head Quantity: 3/4 pieces
- Inks: UV ink
- RIP Software: PhotoPrint or Print Factory
Wit-Color UV printer UVIP Epson 6090
Use High Resolution for All Advertising Images
1. Epson Print head
2. Maximum printing area is 0.6m * 0.9m
3. High Quality! High Resolution, Better Performance!
Removable Rail Beam, Suitable for Thicker Materials
The printer features an innovative liftable rail beam design that allows it to easily accommodate thicker materials. This adaptability is ideal for a wide range of printing applications, from traditional paper and cardstock to more durable substrates such as wood, plastic and metal. Whether you’re working on custom signage, packaging or industrial components, the adjustable rail beam ensures precise and consistent results across different material thicknesses.
Precision Printing, Small Space Requirement
Designed for precision, this printer delivers high-resolution, precise prints that capture even the finest details. Its compact design means it requires minimal space, making it a great choice for small studios, offices or workshops where space is at a premium. Despite its small footprint, the printer doesn’t compromise on quality, delivering sharp, vibrant prints every time.
Small Investment, High-Quality Output
Investing in this printer offers exceptional value, combining affordability with top-tier performance. Even with a modest initial investment, users can produce high-quality prints that rival more expensive machines. This balance of cost-effectiveness and superior output is a smart choice for businesses looking to maximize their return on investment without compromising on print quality.
Industrial-Grade Configuration, Stable and Durable
Built in an industrial-grade configuration, this printer is built to last. Its robust design ensures stability during operation, reducing the risk of mechanical issues and downtime. Durable components and materials mean the printer can handle high-volume production runs and harsh environments, making it a reliable workhorse for any industrial printing need.
Model | UVIP6090 | |||
Print Technology | UV Printing | |||
Print Head | Epson i3200 | |||
Acceptable Media | Type | Metal Plate, Glass, Wooden Board, Acrylic, Mobile Phone Cases etc. | ||
Width | ≦600*900mm | |||
Thickness | ≦130mm | |||
Weight | ||||
Ink Type | UV Ink :CMYK LCLM WV | |||
Ink Supply | Negative Pressure Ink Supply | |||
Ink Cartridges | Capacity | Color Syphon+White ink automatic mixing | ||
Color | CMYK+LC、LM+W+Varnish | |||
Image Format | Tiff, JPEG, EPS, PDF | |||
RIP Software | Photo Printing (Standard) PrintFactory/Onyx /Caldera (optional) | |||
Print Resolution | Maximum | |||
Speed | Mode | Full Color | H+K | W+C+V |
High Resolution Mode | 18㎡/hour | 12㎡/hour | 6㎡/hour | |
Standard Mode | 27㎡/hour | 18㎡/hour | 9㎡/hour | |
Production Mode | 36㎡/hour | 24㎡/hour | 12㎡/hour | |
Ink Curing Method | Dual UV LED Lights | |||
Control System | Win10 | |||
Power | 3600W | |||
Interface | Gigabit Ethernet | |||
Power Supply | AC 220V±10%, 50/60 HZ | |||
POWER SUPPLY | 3KVA | |||
Air Supply | None | |||
Interface | Gigabit Ethernet | |||
Power Supply | AC 220V±10%, 50/60 HZ | |||
POWER SUPPLY | 3KVA | |||
Air Supply | None | |||
Packaging Size | Inch | L:68.90 x W:72.83 x H:37.40 1 Inch=25.4 mm | ||
Meter | L:1.75mx W:1.85mx H:0.95m | |||
Printer Size | Inch | L:64.96 x W:49.21 x H:59.84 1 Inch=25.4 mm | ||
Meter | L:1.65mx W:1.25mx H:1.52m | |||
Weight | NW 726 lbs. 330kg 1kg =2.2lb. GW 990lb. 450kg 1kg =2.2 lb. | |||
Environment | Power On | Temperature 59℉ to 90℉[15℃ to 32℃] Humidity: 35% to 80% (No Condensation) | ||
Power Off | Temperature 41℉ to 104℉[5℃ to 40℃] Humidity: 35% to 80% (No Condensation) | |||
Safety Certificate | CE Certified |
✱About 10% speed may vary depending on different feather printing modes and different PC configurations. All data is subject to change without notice.
