Yaselan Binary Star S10
Double Sided Textile Printing Machine
Various Printhead Layout Modes
Supports C M Y K / C M Y K LC LM O B (FM,FY) 8 spot color customization solutions.
Machine Features
- Double-sided progressive printhead layout Supports Ricoh (GEN6) or Epson printhead (i3200-A1) high-speed printing.
- Image size parameters can be freely adjusted according to design requirements. Various special application solutions such as same image same color, same image different color, different image different color are achieved.
- Automatic dampening, ink cleaning system, X-Y-Z axes move synchronously. Automatic ink cleaning system effectively cleans the ink splashes generated during printing.
- Two carriages synchronize printing and automatically adjust the distance between the printing media. Support printing on soft roll media up to 2mm.
| Technical Parameters | |
|---|---|
| Printer Model | S10 |
| Print Head | Ricoh GEN6 (8-16), Epson i3200-A1 (4-8) |
| Print Speed (Vehicle Mode) | Ricoh: 635x600 dpi – 80 m²/hour, Epson: 635x600 dpi – 50 m²/hour |
| Print Speed (Production Mode) | Ricoh: 635x900 dpi – 55 m²/hour, Epson: 635x900 dpi – 40 m²/hour |
| Print Speed (High Resolution Mode) | Ricoh & Epson: 635x1200 dpi – 30 m²/hour |
| Ink Type | Acid ink, Acid reactive ink, Direct printing ink, Pigment ink |
| Ink Colors | M / Y / C / K / LM / LC (O, B, FM, FY optional) |
| Media Maximum Width | 350mm (Customizable) |
| Printing Width | 1600 mm |
| Print Thickness | ≤3 mm |
| RIP Software | Maintop / PrintFactory / NeoStampa |
| Image Format | TIFF / JPG / EPS / PDF |
| Data Transfer | TCP/IP Network Interface / USB |
| Operating System | Windows 7/10 64 Bit (Specialized Professional Edition) |
| Computer Configuration | Hard disk: 4T/SSD, Motherboard: INTEL, CPU: i7, RAM: 8G-16G |
| Drying System | Synchronized drying (front & back). Temperature can be adjusted. |
| Ink Cleaning System | Automatic ink cleaning, ink scraping, moisturizing |
| Media Type | Textile fabrics: animal and vegetable protein, cotton, silk, etc. |
| Maximum Power | 22KW (including heating system 20KW) |
| Working Environment | Humidity: 40-70%, Temperature: 20-30°C |
| Power Supply | AC380V ±10% |
| Net Weight | 1400 kg |
| Machine Size | 3890*1738*1977 mm (L*W*H) |
| Package Size | 4090*1768*2270 mm (L*W*H) |
